5Y Series - analytical balances

Technical specifications

Readability from 0.002 mg to 1 mg
Maximum capacity from 41 g to 3100 g
Four model families: XA 5Y.A, XA 5Y, AS 5Y and XA 5Y.F
Automatic or semi-automatic levelling depending on model
Selected models support 21 CFR Part 11 compliance

Model comparison overview

XA 5Y.A

Readability: 0.002–0.1 mg
Capacity: 41–520 g
Automatic levelling
Automatic weighing chamber doors
Integrated antistatic ionizer

XA 5Y

Readability: 0.01–0.1 mg
Capacity: 52–520 g
Semi-automatic levelling
Manual weighing chamber doors

AS 5Y

Readability: 0.01–1 mg
Capacity: 60–3100 g
Semi-automatic levelling
10″ colour touchscreen
21 CFR Part 11 compliance module

XA 5Y.F

Readability: 0.01 mg
Capacity: 52–110 g
Internal weighing chamber for filters
Semi-automatic levelling

The RADWAG 5Y Series combines analytical balances for routine laboratory weighing, regulated environments and specialised weighing tasks within a single product family. Depending on the selected model, the series offers readability from 0.002 mg to 1 mg, capacities up to 3100 g and features designed to support efficient laboratory workflows.

The portfolio includes models with automatic or semi-automatic levelling, different weighing chamber configurations and dedicated solutions such as the XA 5Y.F for filter weighing. This allows laboratories to select the most suitable balance according to their measurement requirements and workflow.

Wide measurement range

The series covers readability from 0.002 mg to 1 mg and maximum capacities from 41 g to 3100 g, allowing selection according to both measurement resolution and sample weight.

Multiple balance configurations

The 5Y Series includes four product variants covering general laboratory weighing, highly sensitive analytical measurements, regulated laboratory environments and dedicated filter weighing.

Levelling options

Depending on the model, balances feature automatic or semi-automatic levelling to support correct balance positioning.

Weighing chamber design

Selected models incorporate automatically opened weighing chamber doors, while others use manually operated doors. The XA 5Y.F features an internal chamber specifically designed for filter weighing.
