XA 5Y.M Microbalances

Technical specifications

• Readability from 1 to 5 µg
• Maximum capacity from 6 to 53 g
• Available with automatic or semi-automatic levelling
• Integrated antistatic ionizer on XA 5Y.M.A models
• Available as standard, pipette calibration and stent weighing models

Model comparison overview

XA 5Y.M

• Semi-automatic levelling
• Manual weighing chamber
• Readability: 1–5 µg
• Maximum capacity: 6–53 g

XA 5Y.M.A

• Automatic levelling
• Automatically opened weighing chamber
• Integrated antistatic ionizer

XA 5Y.M.A.P

• Dedicated to piston pipette calibration
• Integrated antistatic ionizer
• Automatic levelling
• Automatically opened weighing chamber

XA 5Y.M.A.S

• Dedicated to stent weighing
• Readability: 1 µg
• Maximum capacity: 6.1 g
• Integrated antistatic ionizer
• Automatic levelling
• Automatically opened weighing chamber

XA 5Y.M Microbalances are designed for laboratory weighing requiring microgram readability together with advanced automation and electrostatic control. The series includes both standard laboratory models and dedicated configurations for specialised weighing tasks.

Selected models combine automatic levelling, automatic weighing chamber operation and an integrated antistatic ionizer to support reliable weighing of samples susceptible to electrostatic effects.

Key features and benefits

Microgram-level weighing

The XA 5Y.M series provides readability from 1 to 5 µg with maximum capacities from 6 to 53 g, depending on the selected model.

Automatic and semi-automatic configurations

The series includes models with either semi-automatic or automatic levelling, allowing laboratories to choose the preferred level of automation.

Integrated antistatic ionizer

XA 5Y.M.A, XA 5Y.M.A.P and XA 5Y.M.A.S models include an integrated antistatic ionizer designed to reduce electrostatic influences during weighing.

Spacious weighing chamber

The weighing chamber measures 199 × 157 × 218 mm and can be disassembled without tools for convenient cleaning.

Dedicated application models

Specialised configurations are available for piston pipette calibration and stent weighing.

Applications

• Precision laboratory weighing
• Pharmaceutical laboratories
• Chemical laboratories
• Biological laboratories
• Medical laboratories
• Physical laboratories
• Piston pipette calibration
• Stent weighing

Optional technical data

• Readability: 1–5 µg
• Maximum capacity: 6–53 g
• Weighing chamber dimensions: 199 × 157 × 218 mm
• Weighing pan diameter: 30 mm
• Tool-free weighing chamber disassembly
